Product Description

JinJiang Stable Technical MFG Co.Ltd

JinJiang Stable Technical MFG Co.Ltd was a company which focus on the cold forming by press and stamping production process.
The stamping metal part can apply to a lot of area ,such as motor part as mounting bracket ,starter bracket ,oil pump bracket ,water pump bracket ,Alternator Mounting Bracket , Muffler Exhaust Mounting Bracket,Starter Brace Bracket,Motor Mount Engine Bracket,gasket etc ....
All the metal stamping part was made by the stamping ,pressing ,press brake ,laser cutting machine ,polishing machine .

Let`s start the journey of metal stamping part within JinJiang Stable Technical MFG Co.Ltd

Gasket apply on the auto part can be as exhaust gasket ,thermostat house gasket,timing gear house gasket,cylinder head gasket,Oil pan Gasket,oil pump gasket ,water pump gasket .

Almost all the two part joint together need a gasket inside So the raw material can be devide into 3 part :Rubber ,Metal ,stainless ,brass ,copper ,Non-Asbestos Fiberglass Textiles

Non-Asbestos Fiberglass Textiles

Brass Metal Exhausted Gasket

Oil pan washer

Non-asbestos fibres include aramid, Kevlar and fibreglass. Aramid is often used for its excellent heat resistance and strength

Copper Header Exhaust Gaskets with better sealing and resist heat over 700 degree

It was made by the laser cutting or stamping

The oil pan brass gasket was made by the stamping or laser cutting

Raw material :Brass

Laser cutting for gasket

Laser cutting was the fast way to produce the gasket for the sample

Capacity:6000KW

Workstation:2000*12000mm

Thickness:1-10mm

Raw material:Brass gasket,steel gasket , Fiberglass Textiles gasket

Vibrating knife cutting machine

Oscillating knife cutting machine

Sometime Fiberglass Textiles gasket was much more easier to burning by laser cutting .
So there was another good option made by the vibrate cutting machine,When we need it for mass production and without want to make a cutting mold ,that was a good option

It was the same idea for making the Fiberglass Textiles gasket ,just we called it as different name ,what we need just input the drawing for machine and setup the start point then the machine will running and feeder raw material by it self

It was also workout for the rubber gasket

Oil pan gasket oil plug washer Progressive Press

Auto part Gasket washer cups heat treatment

Some of the auto part steel washer or gasket was made by the metal part ,when we meeting the customer who need huge QTY we will adpot the Progressive Press stamping ,what we need just input the raw material coil with a feeder the machine can work by itseld keep stamping time and time The capactiy can be over 20000pcs once a day

When we got the request from the customer by drawing said the gasket need to be heat treatment ,we will put all the washer or the auto gasket ,bearing cups inside the Mesh belt furnace ,heat up dip inside oil ,cooling down will run by the belt according the times we were setting .

Non-Asbestos Fiberglass Textiles Gasket

Rubber gasket

Thermostat house gasket,belling house gasket,water pump house gasket,thermostat pipe connector gasket,timing cover gasket,intake mainfold gasket,Crankshaft Seal,oil pump gasket

Oil pan gasket,oil pump gasket,Engine Head Gasket
Manifold Gasket,Intake Gasket,Exhaust Gasket,Gasket Oil Pan,Head Cover Gasket,EGR Valve Gasket,Water Outlet Gasket,Steel,Copper,Carbon
Fiberglass,Composite gasket

Engine Gasket

Being quality oriented manufacturer, we use high quality non-asbestos materials when producing our products. Special adhesive are used in the product to ensure high strength, excellent elasticity and the ability to withstand the effects of extreme temperature and pressure. Tonyco head gaskets are perfect for high-performance diesel cars and OE overhauls. We include most of the gaskets and items you'll need to rebuild an engine.

Oil Filter Gasket, Oil Pump Gasket,Carburetor Gasket,Axle Flange Gasket,Collector Gasket,Trans Case Gasket

Gasket Visual Inspection

The visual inspection system by camer can carry out the work for inspection by maual ,that will improve the quality of the gasket whatever the dimension or the appearance,when the part was out of the tolerance the machine will handle the part into another tank waiting for rework

Oil Filter Gasket, Oil Pump Gasket,Carburetor Gasket,Axle Flange Gasket,Collector Gasket,Trans Case Gasket all was inspect by it

Automatic packing machine

Automatic packing machine ,after the gasket was done by the inspection ,the machine will count and pack by itself
